High quality plastic SJ55/30 Single screw extruder for PC LED tube light

FOB Reference Price:Get Latest Price
$7,200.00 - $8,000.00 / Sets | 1 Set/Sets (Min. Order)
Model Number:
SJ-55/30
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 30 Negotiable
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Application:
pipe,profile
Plastic Processed:
PP,PE,PC
Screw Design:
Single-screw
Place of Origin:
Jiangsu, China
Brand Name:
BEIERMAN
Voltage:
220/380/415V/440V/480V
Dimension(L*W*H):
2500*1200*1200mm
Weight:
1000KG
Certification:
CE
After-sales Service Provided:
Field installation, commissioning and training
Warranty:
1 Year
screw design:
single screw
Model:
SJ55/30
products type:
single screw extruder for PP,PE,PC
Usage:
pipe,profile making machine
gear box:
hard surface and helix gears
control method:
semi-atomatic/PLC automatic control
Contactor,switch:
SIEMENS,Schneider
Temperature controller:
OMRON
Converter:
ABB
Automatic Grade:
automatic/semi-automatic
Power(W):
18.5KW
Supply Ability
Supply Ability:
200 Set/Sets per Year of Single screw extruder SJ55/30
Packaging & Delivery
Packaging Details
Film package,container for SJ-55/30 Single screw extrusion machine
Port
SHANGHAI/NINGBO
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 30 To be negotiated


CE approved single screw extruder specially designed for PP PE pellets ,PC extruding, it also can combine with the PP PE PC pipe production line, PP PE PC profile production line.



We produce Single screw extruder, and also high speed high efficient Single screw extruder.



Single screw extruder is advanced in design,high in output,good in plasticization and low in energy consumption.

The involute gear driving is characterized by low noise,stable running,big bearing capacity and long service life.



Single screw extruder' screw structure also can re-designed accoring to customer's detail raw material and the purposes.



we have many kind of types,such as 25/25;30/25;35/25;45/25;45/28;45/30;50/28;55/30;65/28; 65/30;65/33;70/30;75/33;90/30;90/33;120/15;120/22;120/32;120/33;130/32;150/10;150/30......etc ,some small single screw extruder be equipped as colormark co-extruder ,or lab extruder; some big single screw extruder ,together with our auxiliary machine,will be equipped as whole production line to make pipe,to granule.



Here I offer one of our SJ55/30 Single screw extruder for your reference.

The SJ55/30 generally is used as main extruder to produce LED light PC pipe,T3,T5,T8, co-extrusion head to PC,PE,PVC pipe production line.

Detail parameter of Single screw extruder SJ55/30 as below:



1

Model

SJ55/30

2

design

Single screw extruder

3

Driving motor

18.5KW

4

Screw diameter

55mm

5

L/D ratio

30:1

6

Screw material

38CrMoAIA

7

Screw hardness

HV900-1000

8

Surface treatment

Nitriding layer with thickness:0.6-0.8mm,Polishing

9

Barrel,inner processing

Nitriding layer with thickness:0.6-0.8mm

10

Heating power

4KW*4sections=16KW in total

11

Heater

Cast Aluminum+stainless steel covering

12

Cooling method,power

Air fans:0.18KW*4=0.72KW in total

13

Speed Reducer

spindle wheel swinging reducer

14

Electric cabinet

AC motor, ABB inverter

15

Contactor

SIEMENS

16

Frequency converter

ABB

17

Capacity

50kg/h

18

Voltage

380V,50Hz,3phase(or design according to customer)

19

Plastic processed

PVC,PP,PE,ABS,etc



Advantage:

- world famous brands major parts:

Motorwith SIEMENS

Inverters

with ABB/ FUJI / LG / OMRON
Contactorswith SIEMENS / Schneider
Temperature controllerswith OMRON/ RKC
PLC systemwith SIEMENS/ DELTA



Skilled workers for machines producing

Experience engineers all with passports ready for customers services

Good Prices get from square quantity major parts purchase with lower cost

- Full line running test for customer checking before delivery















- Packaging: poly-wooden cases for single screw extruder SJ55/30, no need fumigate; films packaging

  - We suggest the customer to purchase poly-wooden case packaging; if no, we will fixed the machines on containers walls with steel wires

  - Shipping: By Sea or Train







pre-sales services: we will take customers to visit our factory and check the machines quality from airport/bus station/train stations



- we will re-designed the machines according to customer's different raw material formulations: driving motors power, electric power model, wall thickness of barrel, control method



after sales services: we will offer electric diagram, installation diagram, usage manual



- we will offer the customers online introduction to solve the machines problems/send engineers for customers machines installation, running test, workers training, machines repairmen services.



- we will offer customers spare parts at cost prices all life long of the machines









- BEIERMAN MACHINERY was established by three skilled technician/engineer/sales for plastic extruding line, plastic recycling lines producing, sale and services.

- We have 3000 square meters working house for machines making, there are 40 workers for machines producing and a 5 engineers service team for the machines running test, installation, workers training and machines repairmen.

- we have already get CE and ISO9001 certificated for our machines and factory, which ensured the high quality level of all machines we are producing

- we will attend several home and abroad plastic machines industry fairs to show the customers our quality, machines and services.

- there will be 1-2 new produced machines will be showed to the customers every year.

- we already established cooperation with the customers from Middle East, Southeast Asia and south America countries.







Related Products



single screw extruder in the pipe extrusion line,

PE pipe Diameter rangeMain extruderMain extruder power(KW)Extrusion line Total power(KW)Remark outlets
16-63mm45/333794single outlet
16-63mm65/3375165two cavity
20-160mm65/3375130single outlet
32-125mm60/3375177single outlet
75-250mm75/33110230single outlet
110-400mm90/33185380single outlet
200-400mm90/30160255single outlet
200-400mm90/33185380single outlet
160-500mm90/33+75/33185+110380+230single outlet
160-500m120/33280550single outlet
280-630mm90/33*2185*2380*2single outlet
280-630mm120/33280550single outlet
315-630mm150/33400800single outlet
400-800mm150/33400800single outlet
